- GXH-125Q forward exit dryer
About:
The equipment uses steam heating, a single capacity of 125KG,1425mm large diameter of the inner cylinder, the volume of 2700 liters, large capacity to let the clothes fully spread, the inner cylinder 12.7MM square punching, improve the effect of wind; Touch LCD panel. Shenwen operation, simple operation; A variety of programs, can be freely set according to different linen, side pull-out cotton mesh, easy cleaning and maintenance, forward and out of the design, both isolation, safety fork health, configuration PLC, continuous with the tunnel washing machine, can also carry discharge conveyor belt, save handling time, improve working efficiency. The rear door is quickly discharged in one minute, saving manpower, saving resources, high efficiency, full self-actualization, the inner cylinder static electricity cleaning device, avoid static electricity caused by fire, the main abnormal type, buzzer alarm, and the machine stops running, and can be restarted after troubleshooting, the machine additional lubricating oil device, protective bearing dryer foot height can be customized according to the laundry room site, Long service life and easy maintenance.
1, the use of liquid touch screen, the use of more simple and convenient can set 8 drying procedures, suitable for drying more different types of linen.
2, the selection of a new process of heaters and unique exhaust device, so that the hot air flow smoothly to increase the drying effect.
3, increase the internal rolling capacity, enhance the uniformity of linen by hot air.
4, the internal rolling simple using square punching, increase the opening rate, improve drying efficiency.
5, hot air circulation in the air duct.
