- Press dehydrator
About:
The press is one of the supporting equipment of the tunnel washing machine. After the cloth is pre-washed, main washed and rinsed out of the warehouse, it automatically enters the press for pressing and dewatering. Compared with the traditional press equipment, the press adopts the advanced specially designed edge press head, which can effectively remove the remaining air in the cloth during the press process, prevent the cloth from bursting due to excessive pressure during the press process, and protect the integrity of the cloth to the maximum extent. The pressed linen is transported to the dryer by shuttle conveyor for dispersion and drying.
1.The independent press adopts hydraulic press technology, which is a special equipment for washing dragon;
2. The press base and the upper structure are connected by four columns to ensure the smooth operation of the whole machine;
3.The press bar is made of solid stainless steel and can withstand great pressure;
4. The press rod head is made of natural rubber, the center thickness is 30 mm and the edge thickness is 45 mm. Dendritic surface, press dehydration effect is excellent.
5. Safety door size is large, built-in automatic power off protection device, making the maintenance of the machine convenient and safe.
6.The base has two built-in drainage outlets, which are connected with the washing dragon drain tank.
7. The press is controlled by PLC, built-in nine kinds of press program, the user can switch the appropriate program according to the need, and can change the setting of the press program
8. The user can change the following parameters: maximum pressure, the length of time of each press step, the duration of the highest pressure state, and the rate of pressure increase.
